Jual Paket CCTV Murah ( Merk "AVTech" )
Kami perusahaan yang bergerak di bidang Security Equipment, khususnya CCTV ( Closed Circuit Television ) ingin menawarkan berbagai produk CCTV dan DVR dengan kualitas dan harga bersaing. Kami juga menawarkan produk dalam bentuk
paket ,
satuan dan
partai ( dealer ) . Tentukan pilihan anda sekarang dan dapatkan kepuasan bersama
CCTV Gallery
Seluruh product menggunakan Merk
" AVTech " ( Made in Taiwan ) , dengan garansi resmi selama 2 tahun.
Contact us :
Lindeteves Trade Center
2nd Floor Blok C-10 No.5
Phone & Fax : 021 - 6220 - 0442
E-mail :
[email protected]
Website :
www.cctv-gallery.com
Chat With our
Paket CCTV 4 Channel Paket CCTV 8 Channel Paket CCTV 16 Channel
AVTech DVR ( Include Price & Picture )
Price for DVR Product
4 Channel DVR
AVTech AVC760 AVTech KPD672 8 Channel DVR
AVTech AVC785 AVTech AVC785D AVTech AVC796 AVTech AVC796D AVTech KPD676 16 Channel DVR
AVTech AVC787 AVTech AVC787D AVTech AVC798 AVTech AVC798D AVTech KPD678
AVTech Camera ( KPC Series )
AVTech CCTV Camera - KPC Series
AVTech KPC131 Product Specification
Pick up Element : 1/3" Color CCD image sensor
Number of Pixel : 512(H) x 492(V) <NTSC> 512(H) x 582(V) <PAL>
Resolution : 420 TV Lines
Min. Illumination : 0.3 Lux / F2.0
S / N Ratio ( Signal to Noise ) : More than 48dB (AGC off)
Electronic Shutter : 1/60 (1/50) to 1/100,000 sec
Lens Mount : C/Counter Strike mount changeable
Iris Mode : D.D./ V.D./ AES
AGC : Auto
White Balance : ATW
Video Output : 1.0 Vp-p composite, 75Ω
Microphone : YES
Power Source : DC12V±10%
Current Consumption : 80mA±10%
Dimension (mm)** : 108(L) x 62(W) x 50(H)
AVTech KPC132 Product Specification
Pick up Element : 1/3" Color CCD image sensor
Number of Pixel : 512(H) x 492(V) <NTSC> 512(H) x 582(V) <PAL>
Resolution : 420 TV lines
Min. Illumination : 0.4 Lux / F2.0
S / N Ratio ( Signal to Noise ) : More than 48dB (AGC off)
Electronic Shutter : 1/60 (1/50) to 1/100,000 sec
Lens Mount : C/Counter Strike mount changeable
Lens : f3.6mm / F2.0
Lens Angle : 92.6°
Iris Mode : AES ( Automatic Electronic Shutter )
Automatic Gain Control : Auto
Video Output : 1.0Vp-p composite, 75ΩBNC
White Balance : ATW / HOLD
Power Source : DC12V
Current Consumption : 110mA ±10%
Dimension (mm) : 100(Ø) X 60(H)
Gross Weight : 203.5 gr
AVTech KPC133 Black White Product Specification
Pick up Element : 1/3" AVTECH color CCD image sensor
Number of Pixel : 512(H) x 492(V) <NTSC> 512(H) x 582(V) <PAL>
Resolution : 420 TV lines
Min. Illumination : 0 Lux (IR LED ON)
Effective IR Range : 15 Meters
IR LED : 21 units
S / N Ratio ( Signal to Noise ) : More than 48dB (AGC off)
Electronic Shutter : 1/60(1/50) to 1/100,000 sec
Lens : f3.6mm / F2.0
Lens Angle : 92.6°
Iris Mode : AES ( Automatic Electronic Shutter )
White Balance : ATW / HOLD
Video Output : 1.0Vp-p composite, 75ΩBNC
Power Source : DC12V±10%
Current Consumption : 90mA (IR OFF), 280mA (IR ON)±10%
AVTech KPC135 Product Specification
Pick up Element : 1/3" Color CCD image sensor
Number of Pixel : 512(H) x 492(V) <NTSC> 512(H) x 582(V) <PAL>
Resolution : 500 TV Lines
Min. Illumination :0.3 Lux / F2.0 ; 0.15 Lux / F1.4
S / N Ratio ( Signal to Noise ) : More than 48dB (AGC off)
Electronic Shutter : 1/60 (1/50) to 1/100,000 sec
Lens Mount : C/Counter Strike mount changeable
Iris Mode : D.D./ V.D./ AES
AGC : Auto
White Balance : ATW
Video Output : 1.0 Vp-p composite, 75Ω
Microphone : Built in
Power Source : 230 V AC ±10%
Current Consumption : 1,8 W ±10%
Dimension (mm)** : 118(L) x 62(W) x 50(H)
AVTech KPC136 Product Specification
Pick up Element : 1/3" AVTECH color CCD image sensor
Number of Pixel : 512(H) x 492(V) <NTSC> 512(H) x 582(V)<PAL>
Resolution : 420 TVL
Min. Illumination : 0.4Lux / F2.0, 0Lux (IR ON) 90mA (IR OFF), 280mA (IR ON)
IR LED : 21 units
Effective Range : 15 Meters
S / N Ratio ( Signal to Noise ) : More than 48dB (AGC off)
Electronic Shutter : 1/60 (1/50) to 1/100,000 sec
Lens : f3.6mm / F2.0
Lens Angle : 92.6°
Iris Mode : AES
IP Rating : IP66
Video Output : 1.0 Vp-p composite, 75Ω
Current Consumption : DC12V
Dimension (mm)** : 107.85(L) x 60(W) x 93.8(H)
AVTech KPC138 Product Specification
Pick up Element : 1/3" color CCD image sensor
Number of Pixel : 512(H) x 582(V)
Resolution : 420 TV Lines
Min. Illumination : 0.4Lux 0Lux (IR ON)
IR LED : 21 units
Effective Range : Up to15 m
S / N Ratio ( Signal to Noise ) : More than 48dB (AGC off)
Electronic Shutter : 1/60 to 1/100,000 sec
Lens : f3.6mm / F2.0
Lens Angle : 92.6°
Iris Mode : AES
White Balance : ATW
Video Output : 1.0 Vp-p composite, 75Ω
Power Source : DC12V ±10%
Current Consumption : 90mA (IR OFF), 210mA (IR ON) ±10%
AVTech KPC139 Product Specification
Pick up Element : 1/3" AVTECH color CCD image sensor
Number of Pixel : 512(H) x 492(V) <NTSC> 512(H) x 582(V) <PAL>
Resolution : 420 TV Lines
Min. Illumination : 0.3Lux / F2.0 / 0Lux (IR ON)
IR LED : 35 Units
Effective Range : Up to 25 m
S / N Ratio ( Signal to Noise ) : More than 48dB (AGC off)
Electronic Shutter : 1/60 (1/50) to 1/100,000 sec
Lens : f3.6mm / F2.0
Lens Angle : 92.6°
Iris Mode : AES
White Balance : ATW
IP Rating : IP67
Video Output : 1.0 Vp-p composite, 75Ω
Power Source : DC12V ±10%
Current Consumption : 90mA (IR OFF) / 340mA (IR ON) ±10%
Dimensions (mm)** : 183.69(L) x 85.24(W) x 150(H)
Weight : 430 gr
AVTech CCTV Camera - CM & AVM Series
AVTech CCTV Camera - Other Series
AVTech CM632 Product Specification
Pick up Element : 1/3" HR Color CCD image sensor
Number of Pixel : 771(H) X 492(V) <NTSC> 753(H) X 582(V) <PAL>
Resolution : 520 TV lines
Min. Illumination : 0.2 Lux / F2.0
S / N Ratio ( Signal to Noise ) : More than 48dB (AGC off)
Electronic Shutter : 1/60 (1/50) to 1/100,000 sec
Lens : f3.6mm / F2.0
Lens Angle : 92°
Iris Mode : AES ( Automatic Electronic Shutter )
White Balance : ATW / HOLD
Automatic Gain Control : AGC Max
Back Light Compensation : ON / OFF
Video Output : 1.0Vp-p composite, 75ΩBNC
Power Source : DC12V
Current Consumption : 90mA ±10%
Dimension (mm) : 100(Ø) X 60(H)
Gross Weight : 205 gr
AVTech CM637 Product Specification
Pick up Element : 1/3 Color CCD image sensor
Number of Pixel : 771(H) X 492(V) <NTSC> 753(H) X 582(V) <PAL>
Resolution : 520 TV lines
Min. Illumination : 0.2 Lux / F2.0, 0 Lux ( IR LED ON )
S / N Ratio ( Signal to Noise ) : More than 48dB ( AGC off )
Electronic Shutter : 1/60 (1/50) to 1/100,000 sec
Lens : f3.6mm / F2.0
Lens Angle : 92.6°
IR LED : 24 Units
Effective Range : Over 20 Meters
Iris Mode : AES ( Automatic Electronic Shutter )
White Balance : ATW
Automatic Gain Control : Auto
IP Rating : IP67
Video Output : 1.0 Vp-p composite,75Ω BNC
Power Source : DC12V ±10%
Current Consumption : 90 mA ( IR OFF ), 330 mA ( IR ON )
Dimension (mm) : 100 (L) X 65 (W) X 63.8 (H)
Gross Weight : 320 gr
AVTech AVM157 Product Specification
Pick up Element : 1/3" Color CCD image sensor
Number of Pixel : 510(H) x 492(V) <NTSC> 500(H) x 582(V) <PAL>
Resolution : 420 TVL
Min. Illumination : 0.25Lux / F1.4
IR LED : 24 Units
Effective Range : Over 20 meters
S / N Ratio ( Signal to Noise ) : More than 48dB (AGC off)
Electronic Shutter : 1/60 (1/50) to 1/100,000 sec
Lens : f6.0mm / F1.4
Lens Angle : 56°
D&N Filter Control : Built-in IR Shifter
Line Lock : Optional
Iris Mode : AES
White Balance : ATW
IP Rating : IP66
Video Output : 1.0 Vp-p composite, 75Ω
Current Consumption : 5W max
Dimension (mm)** : 112 (L) 82 (W) 75 (H)
Net Weight : 598 gr
AVTech AVM208 Product Specification
Pick up Element : 1/3" Color CCD image sensor
Number of Pixel : 510(H) x 492(V) <NTSC> 500(H) x 582(V) <PAL>
Resolution : 420 TVL
Min. Illumination : 0.25Lux / F1.4
IR LED : 24 Units
Effective Range : Over 20 meters
S / N Ratio ( Signal to Noise ) : More than 48dB (AGC off)
Electronic Shutter : 1/60 (1/50) to 1/100,000 sec
Lens : f6.0mm / F1.4
Lens Angle : 56°
D&N Filter Control : Built-in IR Shifter
Line Lock : Optional
Iris Mode : AES
White Balance : ATW
IP Rating : IP66
Video Output : 1.0 Vp-p composite, 75Ω
Current Consumption : 5W max
Dimension (mm)** : 112 (L) 82 (W) 75 (H)
Net Weight : 598 gr
AVTech Camera ( GL Series )
AVTech Camera - GL Series
AVTech GL103 Product Specification
Image Device : 1/3" Sony & Sharp CCD sensor
Scanning Frequency :
NTSC: 15,734KHz(H), 60Hz(V);
PAL: 15,625KHz(H),50Hz(V)
Scanning System :
NTSC: 525 line 2:1 interlace
PAL:625 lines 2:1 interlace
Effective Pixels :
NTSC: 512(H) x 492(V)
PAL:512(H) x 582(V)
Electronic Shutter :
NTSC:1/60- 1/100,000 sec (Auto)
PAL:1/50-1/100,000sec (Auto)
Horizontal : 420 TV Lines
White-balance : Auto white balance (2500°K~9500°K)
Synchronizing System : Internal
Sensitivity : 0.1 Lux , 0 Lux at IR on / F2.0
BLC : Auto
Signal to Noise : More than 48dB AGC off
AGC : Yes
Gamma Correction : 0.45
IR Distance : 25 Meters (Based on: object of view reflected IR light)
IR LED : 42 pcs
IR Status : Under 10 Lux by CDS auto control
IR View Angle : View angle: 70°,
Beam spread : 40°/per LED
IR Wavelength : 850nm ± 25nm
LED Life : More than 10,000 hours
Lens : 6 mm Standard (4,8,12,16mm option)
Power Consumption : IR on: 450mA,IR off: 120mA ± 5mA
Power Supply : 12VDC, AC90V~260V (Auto)
Temperature : Operating: -10 to 50°C
Video Output : Composite 1.0 Vp-p at 75 ohm
Construction : ABS with sunshield weatherproof
Dimensions : 110(W) x 100(H) x 260(L) mm
Weight : 900 g
AVTech GL112 Product Specification
Image Device : 1/3" Sony & Sharp CCD sensor
Scanning Frequency :
NTSC: 15,734KHz(H), 60Hz(V)
PAL: 15,625KHz(H),50Hz(V)
Scanning System :
NTSC: 525 line 2:1 interlace
PAL:625 lines 2:1 interlace
Effective Pixels :
NTSC: 512(H) x 492(V)
PAL:512(H) x 582(V)
Electronic Shutter :
NTSC : 1/60- 1/100,000 sec (Auto)
PAL : 1/50-1/100,000sec (Auto)
Horizontal : 420 TV Lines
White-balance : Auto white balance (2500°K~9500°K)
Synchronizing System : Internal
Sensitivity : 0.1 Lux , 0 Lux at IR on / F2.0
BLC : Auto
Signal to Noise : More than 48dB AGC off
AGC : Yes
Gamma Correction : 0.45
IR Distance : 18 Meters (Max.)
IR LED : 35 pcs LED
IR Status : Under 10 Lux by CDS auto control
IR View Angle : 70°,
Beam spread : 40°/per LED
IR Wavelength : 850nm ± 25nm
LED Life : More than 10,000 hours
Lens : 6mm Standard (4,8, 12mm Option)
Power Consumption : IR on: 280mA, IR off: 70mA ± 5mA
Power Supply : 12VDC 500mA (not included)
Temperature : Operating: -10 to 50°C
Video Output : Composite 1.0 Vp-p at 75 ohm
Construction : Aluminum
Dimensions : 75(Ø) x 110(L) mm
Weight : 400 g
AVTech GL113 Product Specification
Image Device : 1/3" Sony & Sharp CCD sensor
Scanning Frequency :
NTSC: 15,734KHz(H), 60Hz(V)
PAL: 15,625KHz(H),50Hz(V)
Scanning System :
NTSC: 525 line 2:1 interlace
PAL:625 lines 2:1 interlace
Effective Pixels :
NTSC: 512(H) x 492(V)
PAL:512(H) x 582(V)
Electronic Shutter
NTSC : 1/60- 1/100,000 sec (Auto)
PAL:1/50-1/100,000sec (Auto)
Horizontal : 420 TV Lines
White-balance : Auto white balance (2500°K~9500°K)
Synchronizing System : Internal
Sensitivity : 0.1 Lux , 0 Lux at IR on / F2.0
BLC : Auto
Signal to Noise : More than 48dB AGC off
AGC : Yes
Gamma Correction : 0.45
IR Distance : 15 Meters ( Max )
IR LED : 28 pcs LED
IR Status : Under 10 Lux by CDS auto control
IR View Angle : 70°
Beam spread: 40°/per LED
IR Wavelength : 850nm ± 25nm
LED Life : More than 10,000 hours
Lens : 6mm Standard
Power Consumption :
IR on: 450mA, IR off: 120mA ± 5mA
Power Supply :12VDC
Temperature : Operating: -10 to 50°C
Video Output : Composite 1.0 Vp-p at 75 ohm
Construction : Aluminum with sunshield weatherproof
Dimensions : 70(Ø) x 120(L) mm
Weight : 400 g
AVTech GL117 Product Specification
Image Device : 1/3" Sony & Sharp CCD sensor
Scanning Frequency :
NTSC:15,734KHz(H), 60Hz(V)
PAL: 15,625KHz(H),50Hz(V)
Scanning System :
NTSC: 525 line 2:1 interlace
PAL:625 lines 2:1 interlace
Effective Pixels :
NTSC: 512(H) x 492(V)
PAL:512(H) x 582(V)
Electronic Shutter :
NTSC : 1/60- 1/100,000sec (Auto)
PAL : 1/50-1/100,000sec (Auto)
Horizontal : 420 TV lines
White-balance : Auto white balance (2500°K~9500°k)
Synchronizing System : Internal
Sensitivity : 0.2 Lux , 0 Lux at IR on / F2.0
BLC : Auto
Signal to Noise : More than 48dB (AGC off)
IR Distance : 25 Meters (Based on: object of view reflected IR light)
IR LED : High Light LED x 56 pcs
IR View Angle : 70°
Beam spread: 40°/per LED
IR Wavelength : 850nm ± 25nm
LED Life : More than 10,000 hours
Lens : 6 mm Standard (4,6,8,12mm option)
Power Consumption : IR on: 500mA, IR off: 80mA (DC 12V) ± 5mA
Power Supply : DC 12V
Temperature : Operating: -10 to 50°C
Video Output : Composite 1.0 Vp-p at 75 ohm
Construction : Aluminum with sunshield weatherproof
Dimensions : 95(W) x 90(H) X 160(L) mm
Weight : 0.450kg
AVTech GL123 Product Specification
Image Device : 1/3" Sony & Sharp CCD sensor
Scanning Frequency :
NTSC: 15,734KHz(H), 60Hz(V)
PAL: 15,625KHz(H),50Hz(V)
Scanning System :
NTSC: 525 line 2:1 interlace
PAL:625 lines 2:1 interlace
Effective Pixels :
NTSC: 512(H) x 492(V)
PAL:512(H) x 582(V)
Electronic Shutter :
NTSC : 1/60- 1/100,000 sec (Auto)
PAL:1/50-1/100,000sec (Auto)
Horizontal : 420 TV Lines
White-balance : Auto white balance (2500°K~9500°K)
Synchronizing System : Internal
Sensitivity : 0.1 Lux , 0 Lux at IR on / F2.0
BLC : Auto
Signal to Noise : More than 48dB AGC off
AGC : Yes
Gamma Correction : 0.45
IR Distance : 25 Meters (Max.)
IR LED : 42 pcs
IR Status : Under 10 Lux by CDS auto control
IR View Angle : 70°,
Beam spread : 40°/per LED
IR Wavelength : 850nm ± 25nm
LED Life : More than 10,000 hours
Lens : 6mm Standard (4,8, 12mm Option)
Power Consumption : IR on: 380mA, IR off: 70mA ± 5mA
Power Supply : AC24,AC90~240V(AUTO) AC24V
Temperature : Operating: -10 to 50°C
Video Output : Composite 1.0 Vp-p at 75 ohm
Construction : Aluminum
Dimensions : 142(w)96(H) x242(L) mm
Weight : 05.kg
CCTV Camera
CCTV adalah penggunaan Video Camera untuk menampilkan gambar pada waktu dan tempat tertentu CCTV merupakan kepanjangan dari Closed Circuit Television, yang berarti menggunakan signal yang bersifat tertutup, tidak seperti televisi biasa yang merupakan broadcast signal. pada umumnya CCTV digunakan sebagai pelengkap keamanan dan banyak dipakai di dalam industri industri seperti : Militer, Airport, Toko, Kantor dan pabrik
|
JAKARTA |
BANDUNG |
PEKANBARU |
SURABAYA |
SEMARANG
|
